产品简介
该系列产品兼容GJB599Ⅲ系列安装尺寸，卡口式连接，采用12芯、24芯MT接触件发展成的一种耐环境高密度圆形光纤连接器。采用三级引导定位，具有五键识别、防错插、防斜插、盲插等特点。外壳体可选用不同的材料及镀层适应不同的环境要求。

主要技术指标
机械性能
● 机械寿命：500次插拔循环
● 冲击：加速490m/s 2 ，11ms
● 振动：10～2000Hz，加速度147m/s 2
环境性能
● 温度范围：-40℃～+80℃
● 盐雾： K类：1000h F类：48h
光学性能
● 插入损耗：≤0.6dB

注：本产品有全国产化型号可选
Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
