EDFA光纤放大器

EDFA光纤放大器

EDFA掺铒光纤放大器

常用别名:Erbium Doped Fiber Application Amplifier;Erbium Doped Fiber Amplifier
缩写:EDFA
来历:Er-Doped Fiber Amplifier

EDFA掺铒光纤放大器分类


1.功率放大器(booster-Amplifier),处于合波器之后,用于对合波以后的多个波长信号进行功率提升,然后再进行传输,由于合波后的信号功率一般都比较大,
所以,对一功率放大器的噪声指数、增益要求并不是很高,但要求放大后,有比较大的输出功率。
2.线路放大器(Line-Amplifier),处于功率放大器之后,用于周期性地补偿线路传输损耗,一般要求比较小的噪声指数,较大的输出光功率。
3.前置放大器(Pre-Amplifier),处于分波器之前,线路放大器之后,用于信号放大,提高接收机的灵敏度(在光信噪比(OSNR)满足要求情况下,较大的输入功率可以压制接收机本身的噪声,提高接收灵敏度),要求噪声指数很小,对输出功率没有太大的要求。

波分复用器

CATV系统用光纤放大器

CATV系统用光纤放大器

CATV系统用光纤放大器:该产品为高功率拉曼光纤放大器产品。主要用于低噪声,长跨距或高速率光纤传输系统,利用传输光纤作为增益介质形成分布式放大,有效降低系统噪声,可与本公司EDFA产品组合使用得到最佳的增益与噪声指标。 每只Pump输出功率现场独立可调,更适应各种不同的网络应用和放大带宽。 智能化监控与管理系统。独特的具有RS232,RS485和以太网三种网管接口,且开放的网管接口,保证与任何的网管系统的互联性。

Compact Variable Gain EDFA

Compact Variable Gain EDFA

Compact 70x90 mm Variable Gain EDFA:F-tone's Compact 70x90 mm Variable Gain (VG) EDFA is a micro processor-controlled module for C-band amplification. The Compact VG module is packaged in a 70x90 mm amplifier package, providing drop-in replacement software and hardware compatibility to line cards already designed to accommodate fixed gain EDFA.

电信多通道DWDM光纤放大器

C波段单通道掺铒光纤放大器

C波段单通道掺铒光纤放大器:FTA-1550CT系列是C波段单通道光纤放大器,即增益平坦光纤放大器,由于C波段光纤放大器, 与光纤的低损耗波段一致且其技术已比较成熟,所以得到广泛应用。掺铒光纤是EDFA的核心原件,它以石英光纤作基质材料,并在其纤芯中掺入一定比例的稀土 原素铒离子(Er3+)。

DWDM EDFA Series

DWDM EDFA Series

DWDM EDFA Series:The product is high stability output EDFA. The stability Pump optical maser and unique ATC (automatic temperature control) and APC (automatic power control) circuit are employed in it as the key component to ensure the high stability and reliability of output power;The unique optical circuit design ensures the excellent optical character.

EDFA掺铒光纤放大器

EDFA掺铒光纤放大器

掺铒光纤放大器(EDFA)是光纤通信系统中广泛应用的一种重要器件。在光纤通信系统中,掺铒光纤放大器(EDFA)一般用于前置放大、功率提升和在线放大等。用于SDH 长途干线网,城域网;千兆以太数据网,接入网;DWDM传输系统。高输出光功率;低噪声,低功耗;工作波长范围宽;标准 RS-232 监控接口或 RJ-45 网管接口,符合 SNMP 标准协议



Fixed Gain EDFA

Fixed Gain EDFA

F-tone's 70x90 mm Fixed Gain EDFA product line supports a full range of C- or L-band fixed gain WDM EDFAs, as well as narrow band, CWDM and single channel EDFAs. The products support either cooled or uncooled pumps, allowing the optimal combination of size, power consumption and performance to be achieved for each application.

FTTH用高功率光纤放大器

FTTH用高功率光纤放大器

FTTH用高功率光纤放大器:该产品为高功率输出C-Band Er-Yb 共掺双包层光纤放大器。核心器件采用高可靠性的多模Pump激光器和双包层光纤,采用独特的APC(自动功率控制)和ATC(自动温度控制)电路,使得输 出功率稳定度高、可靠性好;独特的光路设计保证优秀的光路指标;采用高稳定和高精度的MPU(微处理器)系统使调节、显示方便、可靠、智能。

High Power Fixed Gain EDFA

High Power Variable Gain / Fixed Gain EDFA

High Power Variable Gain / Fixed Gain EDFA:F-tone's High Power Variable Gain / Fixed Gain EDFA module provides up to 26dBm output power using standard telecom grade single-clad broadband technology. This high output power is critical in applications requiring an improved optical signal to noise ratio (OSNR), such as long repeaterless links, long span masking in multi-span links, and high capacity systems.

Hybrid Raman-EDFA

Hybrid Raman-EDFA

F-tone's Hybrid Raman-EDFA module enables cost-effective deployment of ultra-long haul networks as well as the extension of existing long-haul, regional and metro networks, without the need for 3R O-E-O regeneration. The Hybrid module consists of a counter-propagating Raman pump unit and a variable gain (VG) EDFA.

Optical Supervisory Channel (OSC) EDFA

Optical Supervisory Channel (OSC) EDFA

Optical Supervisory Channel (OSC) EDFA:F-tone's Optical Supervisory Channel (OSC) EDFA is designed to be used as a booster amplifier for a 1510 nm OSC. This unique EDFA, provided in a compact 70x90x15 mm MSA form factor, provides up to 12 dBm output power in the 1503-1517 nm band, thus significantly extending the link reach of the OSC.

Raman Amplifier Module

Raman Amplifier Module

Raman Amplifier Module:F-tone's Raman amplifier module is an intelligent pump unit for distributed Raman amplification. The Raman amplifier module can accommodate two or three pumps (multiple wavelengths) for C or L-band amplification, and includes full and comprehensive electronic control. The dual and triple-pump models have a maximum output power of 700 mW and 1 W, respectively. Using patent pending technology, the Raman pump unit can operate in full automatic gain control (AGC) mode, thus allowing the Raman gain to be set with an accuracy of +/-0.7 dB.

DWDM EDFA Series

Single Channel EDFA Series

Single Channel EDFA Series:The product is high stability output EDFA. The stability Pump optical laser and unique ATC (automatic temperature control) and APC (automatic power control) circuit are employed in it as the key component to ensure the high stability and reliability of output power, The unique optical circuit design ensures the excellent optical character

Single Channel Micro EDFA

Single Channel Micro EDFA

Single Channel Micro EDFA:F-tone's Single Channel Micro EDFA is a cost-effective micro processor-controlled module for amplifying single channels in the C-band. The amplifier is provided in a micro 45x70x12 mm package, and exhibits low power consumption allowing it to be easily integrated onto space and power constrained transponder line cards.

Stand Alone 1RU EDFA

Stand Alone 1RU EDFA

Stand Alone 1RU EDFA:F-tone's Stand Alone 1RU EDFA comprises one or two F-tone EDFA modules, packaged within a rack-mountable 1RU unit. This unit can be operated as a fully independent network element using a comprehensive and user-friendly GUI or SNMP/RS232 communications, and is an excellent solution for immediate deployment of EDFA-based systems.

Variable Gain Dual Stage EDFA

Variable Gain Dual Stage EDFA

F-tone's Variable Gain Dual Stage EDFA provides flattened gain across the C-band, low noise figure, and a large dynamic gain range (up to 15 dB). The product includes advanced features such as comprehensive transient control, tunable mid-stage access (MSA) loss, and gain tilting functionality. The Variable Gain Dual Stage EDFA can be implemented in all network segments (long-haul, regional, metro and access) and for all network applications (telecom, cable and enterprise).
