产品简介
● 兼容J599III系列连接器安装尺寸；
● 适用于航空、电子、舰船、兵器等系统，安装空间较小的场合，旋转快锁，实现多路光通信
● 外壳体可选用不同材料及镀层适应不同环境要求
● 五键定位，有盲插和防错插功能
● 卡口式结构，快速连接
● 采用陶瓷插针和套管实现光学精密对接

主要技术指标
机械性能
● 机械寿命：500次插拔循环
● 冲击：加速980m/s ² ，11ms 冲击：加速980m/s ，11ms
● 振动：10～2000Hz，加速度147m/s ²
● 抗拉力：≥68N（适配Φ2光缆的接触件）
环境性能
● 温度范围：-40℃～+80℃
● 盐雾： K类：1000h F类：48h W类：500h
光学性能
● 插入损耗：≤0.6dB

注：本产品有全国产化型号可选
Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
