785nm窄线宽激光器系统

785nm窄线宽激光器系统

0.0/5 rating (0 votes)

Description

产品简介
北亿纤通的785nm激光器系统内置北亿纤通自产的窄线宽激光器,通过专有的电路设计实现快速的激光驱动。该激光系统具有窄线宽、稳定波长、稳功率、稳光谱输出等优点,非常适用于拉曼光谱、传感、医疗以及其他测量等领域的应用。
应用领域
● 拉曼光谱
● 传感
● 医疗
● 生物仪器
技术参数
参数 符号 最低值 典型值 最大值 单位
输出功率 Po 500
中心波长 λc 784.5 785 785.5 nm
光谱半高宽度 FWHM 0.1 nm
边模抑制比 SMSR 40 dB
波长稳定性 △λ ±0.005 nm(@8H)
功率稳定性 △P ±1.5 %(@8H)
功率调整范围 0 100 %
预热时间 15 min
模拟调制输入信号(TTL控制) Mod 0 2.5 V
电源输入 U 100 240 VAC(50-60Hz)
工作温度 To 10 25 35
储存温度 Ts -10 60
控制接口 USB,BNC
光纤接口 105um,0.22NA

备注:*. 1、TTL控制输出功率,Po=ModX200(±10%)

        2、USB控制输出功率,Po=0∽500(±10%)
外形尺寸73







Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
