QSFP-DD光模块

QSFP-DD光模块

QSFP-DD光模块,QSFP-DD光纤模块,QSFP-DD 200G光模块,QSFP-DD 200G光纤模块,QSFP-DD 400G光模块,QSFP-DD 400G光纤模块;目前QSFP28光模块有四个电通道,每通道运行速率为10Gbps或25Gbps,支持40G和100G以太网应用。新成立的QSFP-DD小组计划将通道数增加到八个,通过NRZ调制使每通道运行速率上达25Gbps或通过PAM4调制每通道运行速率上达50Gbps,从而支持200Gbps或400Gbps光传输。该MSA小组表示,在400Gbps传输速率下,该QSFP-DD封装能让单一交换机插槽的汇总带宽达到14.4zbps,能满足快速增长的数据中心流量增长。

P/NProduct DescriptionData Rate (Gbit/s)ReachTXRXPower ConsumptionTemperature (deg C)
FT-QSFPDD-AOC-xxx 400G QSFP-DD AOC 400G 30m VCSEL PIN <9W (for each end) 0-70/-40~85可选
FT-QSFPDD-SR8 400G QSFP-DD SR8 400G 100m VCSEL PIN <9W 0-70/-40~85可选
FT-QSFPDD-DR4 400G QSFP-DD DR4 400G 500m Uncooled EML PIN <10W 0-70/-40~85可选
FT-QSFPDD-FR4 400G QSFP-DD FR4 400G 2km Uncooled EML PIN <10W 0-70/-40~85可选
FT-QSFPDD-LR8 400G QSFP-DD LR8 400G 10km Cooled EML PIN <13W 0-70/-40~85可选
FT-QSFPDD-ER8 400G QSFP-DD ER8 400G 40KM coming soon coming soon coming soon 0-70/-40~85可选
FT-QSFPDD-ZR8 400G QSFP-DD ZR8 400G 80KM coming soon coming soon coming soon 0-70/-40~85可选

QSFP-DD光模块

 400G QSFP-DD 70m/100m Optical Transceiver

400G QSFP-DD 70m/100m Optical Transceiver

400G QSFP-DD 70m/100m Optical Transceiver

Product Description
F-tone Networks’s QSFP-DD transceiver module is designed for use in 400 Gigabit Ethernet links over 70m OM3 or 100m OM4 fiber. The module has 8 independent electrical input/output channels operating at 53.125Gbps per channel. This transceiver consists of two transmitter/receiver units, with each operating on 850nm wavelength.

 400G QSFP-DD to 8x 50G SFP56 AOCOC

400G QSFP-DD to 8x 50G SFP56 AOCOC

400G QSFP-DD to 8x 50G SFP56 AOCOC

设计为2x200G以太网200G-SR4到8X50G以太网50G-SR互连多个850nm多模光纤。

100G-QSFP28-12

100G-QSFP28-12

100G-QSFP28-12

100G-QSFP28-12 is Multi-Vendor MSA Compatible 100GBASE-LR4 QSFP28 (Quad Small Form-Factor Pluggable 28) Transceiver, operating over pair of single-mode optical fiber with four independent optical communication lanes, separated from each other using LAN WDM technology.

100G-QSFP28-2

100G-QSFP28-2

100G-QSFP28-2

100G-QSFP28-102 is Multi-Vendor MSA Compatible 100GBASE-PSM4/IR4 QSFP28 (Quad Small Form-Factor Pluggable 28) Transceiver designed for operation over single-mode optical fiber.

100G-QSFP28-2.1

100G-QSFP28-2.1

100G-QSFP28-2.1

100G-QSFP28-2.1 is Multi-Vendor MSA Compatible 100G QSFP28 CWDM4 (Quad Small Form-Factor Pluggable 28) Transceiver, operating over pair of single-mode optical fiber. Module adopts CWDM MUX/DEMUX technology with central wavelength of the lanes at: 1271, 1291, 1311, 1331 nm.

100G-QSFP28-2.1

100G-QSFP28-2.1

100G-QSFP28-2.1

100G-QSFP28-2.1 is Multi-Vendor MSA Compatible 100G QSFP28 CWDM4 (Quad Small Form-Factor Pluggable 28) Transceiver, operating over pair of single-mode optical fiber. Module adopts CWDM MUX/DEMUX technology with central wavelength of the lanes at: 1271, 1291, 1311, 1331 nm.

100G-QSFP28-20

100G-QSFP28-20

100G-QSFP28-20

100G-QSFP28-20 is Multi-Vendor MSA Compatible 100GBASE-LR4 QSFP28 (Quad Small Form-Factor Pluggable 28) Transceiver, operating over pair of single-mode optical fiber with four independent optical communication lanes, separated from each other using LAN WDM technology.

100G-QSFP28-40

100G-QSFP28-40

100G-QSFP28-40

100G-QSFP28-40 is Multi-Vendor MSA Compatible 100GBASE-ER4 Lite QSFP28 (Quad Small Form-Factor Pluggable 28) Transceiver, operating over pair of single-mode optical fiber with four independent optical communication lanes, separated from each other using LAN WDM technology.

100G-QSFP28-40

100G-QSFP28-40

100G-QSFP28-40

100G-QSFP28-40 is Multi-Vendor MSA Compatible 100GBASE-ER4 Lite QSFP28 (Quad Small Form-Factor Pluggable 28) Transceiver, operating over pair of single-mode optical fiber with four independent optical communication lanes, separated from each other using LAN WDM technology.

100G-QSFP28-80

100G-QSFP28-80

100G-QSFP28-80

100G-QSFP28-80 is Multi-Vendor MSA Compatible 100GBASE-ZR4 QSFP28 (Quad Small Form-Factor Pluggable 28) Transceiver, operating over pair of single-mode optical fiber with four independent optical communication lanes, separated from each other using LAN WDM technology.

100G-QSFP28-SL2

100G-QSFP28-SL2

100G-QSFP28-SL2

100G-QSFP28-SL2 is Multi-Vendor MSA Compatible 100G-FR Single Lambda PAM4 QSFP28 (Quad Small Form-Factor Pluggable 28) Transceiver, operating over pair of single-mode optical fiber.

100G-QSFP28-SL500

100G-QSFP28-SL500

100G-QSFP28-SL500

100G-QSFP28-SL500 is Multi-Vendor MSA Compatible 100G-DR Single Lambda PAM4 QSFP28 (Quad Small Form-Factor Pluggable 28) Transceiver, operating over pair of single-mode optical fiber.

100G/400G QSFP-DD DCO

100G/400G QSFP-DD DCO

100G/400G QSFP-DD DCO

F-tone Networks QSFP-DD product family is designed based on dual polarization quadrature phase shift keying (DP-QPSK) or dual polarization quadrature amplitude modulation (DP-16QAM) or probabilistic constellation shaping quadrature amplitude modulation (PCS-16QAM), supporting extended C-band, polarization diversity coherent detection and advanced electronic link equalization.

200G QSFP-DD AOC

200G QSFP-DD AOC

200G QSFP-DD AOC

设计用于多个850nm多模光纤上的2x 100G以太网100GABSE-SR4互连。

QSFP28-OTU4-LR4光模块

200G QSFP-DD PSM8 10km

200G QSFP-DD PSM8 10km

北亿纤通(F-tone Networks)200G QSFP-DD PSM8光模块专为多个单模光纤上的2x100G以太网PSM4链路而设计,支持使用1310nm波长传输距离达10km。
