Y50X系列圆形电连接器

Y50X系列圆形电连接器

0.0/5 rating (0 votes)

Description

Y50X系列圆形电连接器

产品简介
Y50X系电连接器符合GJB101A-1997标准,参照美军标MIL-C-26482标准,连接方式为卡口式快速链接和快速分离,具有体积小、密度高耐环境好可靠性高等优点,广泛应用于航空、航天、航海、野战、战车、公交电力、邮电通信、铁路指挥系统等电气及电子设备的线路连接,并可根据用户需求改装成滤波连接器。

产品技术特性
使用环境条件工作温度:-55℃~+125℃
相对湿度:40℃±2℃时,90%~95%
工作气压:4.39kPa~101.33kPa
防 雨:符合GJB101A—97中3.6.17规定,按4.6.17方法进行试验
盐雾:符合GJB1217A-97中3.6.13规定,按4.6.13方法进行试验
霉菌:符合GJB101A-97中3.6.2规定,按4.3.2方法进行试验
振动:10Hz~2000Hz
           加速度196m/s²
冲击:加速度980m/s²
碰撞:加速度392m/s²机械寿命:插拔归≥1000次

C56C56C56C56C56













 本产品为FT-BH系列圆形电连接器,如有需要,请联系我们。

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
