Operating Wavelength(nm)

850 or 1300,others on request

Bandwidth(nm)

±40

Grade     Coupling Ratio

Max. Insertion Loss (dB)

P

A

50/50

3.90

4.00

40/60

4.90/3.0

5.00/3.10

30/70

6.20/2.30

6.30/2.40

20/80

8.0/1.70

8.10/1.80

10/90

11.40/1.10

11.60/1.20

Directivity(dB)

≥40

Operation temperature(℃)

-10 to+70

Storage Temperature(℃)

-40 to +85

Configuration

1X2(2X2)

Dimensions(ΦXL)(mm)

250μm bare fiber

Φ3.0X45

900μm loose tube

Φ3.0X54

900μm/2mm/3mm loose tube

90X20X10

a

b

c

d

e

f

g

h

I

Mode

Grade

Wavelength

Package Spec

Fiber dia

Fiber Type

Fiber Diameter

Fiber Length

Connector

S:Single window

D:Dual window

P: Grade P

A: Grade A

X: Others

85:850nm

13: 1310nm

850/1310

850/1310nm

X:Others

1：Φ3mm×54mm

2：Φ3mm×56mm

3：Φ4mm×65mm

4：Φ3mm×70mm

5：90×20×10mm

6：100×80×10.5mm

7：120×80×18mm

8：140×115×18mm

9：2.4mm×30mm

10：3.0mm×35mm

11：3.0mm×45mm

X: Others

50:50/125

62.5:62.5/125

X: Others

OM1

OM2

OM3

OM4

25:250um

90:900um

20:2.0mm

30: 3.0mm

X: Others

05:0.5m

10:1.0m

15:1.5m

X:Others

OO:None

FP:FC/PC

FA: FC/APC

SP: SC/PC

SA: SC/APC

STP: ST/PC

STA: ST/APC

LP: LC/PC

LA: LC/APC

X: Others
