产品简介

● 适配VPX的光纤连接器,符合VITA 66标准
● 采用标准MT接口,高密度、小型化、集成度高
● 体积小、重量轻
● 外壳体可选用不同材料及镀层适应不同环境要求
● 产品适用于航空、电子、兵器、舰船等系统
● 执行企业标准:Q/21EJ755

主要技术性能

● 插入损耗:<0.8dB(多模)，≤1dB(单模)
● 工作温度:-55℃~+85℃
● 振动:10Hz~2000Hz.加速度:147m/s²
● 冲击:490m/s²,半正弦波,11ms
● 机械寿命:500次

注：本产品有全国产化型号可选
