MXC® 至 MTP 组件

MXC® 至 MTP 组件

0.0/5 rating (0 votes)

Description

MXC® 至 MTP 组件

最新的 MXC® 光学互联解决方案,利用扩束 MT 技术,实现尖端的高密度互联。它为嵌入式光学引擎提供了一个直接的卡缘接口,用于各种设备接口应用。
F-tone Networks 已获得 USConec 认证,作为认可制造商,以使用最新的 MXC® 连接器,提供完全定制的光纤组件。我们的MXC®到MTP / MPO光缆组件是一种便捷的解决方案,可将MXC®接口转换为单独的MTP / MPO,以连接到有源光学模块。



功能与应用:
● 尖端的高密度
132 个 MXCTM 适配器可装入 19" 1U 板,增加 40% 面板空间和 59% PCB 区域

● 对碎片和污染敏感度较低
带扩束 MT 技术的嵌入式套圈

● 降低成本、复杂性及占地面积
消除了传统的适配器,并减少了组件数量

● 用于光背板的高速连接解决方案
通过使用单端 MXC 适配器,另一端 MTP/MPO,从 PCB 到卡边缘的便捷连接

● 每秒太比特的带宽能力
64 根光纤,每根以 25Gbps 传输数据,每个连接器允许 1.b TBit/s



 装配结构图:

部件描述: MXC适配器至 MTP 插头,24 光纤,OM3,Mini-core光缆



 47











Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
