Analog Optical Receiver with Pigtail

Analog Optical Receiver with Pigtail

0.0/5 rating (0 votes)

Description

Features
◆Small size:22mm*17mm*8.9mm
◆High responsivity: typical 0.8 mA/mW @ 1310nm
◆Operating frequency up to 24GHz
◆Wide wavelength range from 800nm to 1650nm
◆DC-block and matched to 50 Ohm

Applications
◆5G/4G/3G Mobile Communication
◆Antenna remoting
◆Satellite communications
◆GPS signal transport
◆Pulse signal transport
◆Distributed antenna system
◆High speed test and measurement
◆Video signal distribution in HFC and FTTx Nodes28282828






Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
