40Gbps QSFP+ Transceiver, Multi Mode, 300m Reach

Product Features

• 4 channels full-duplex transceiver modules
• 10.3125Gb/s data rate per channel
•  4 channels 850nm VCSEL array
• 4 channels PIN photo detector array
• Single MPO connector receptacle
• Hot Pluggable QSFP+ form factor
• Maximum link length of 300m on OM3 Multimode Fiber (MMF) and 400m on OM4 MMF
• Compatible with RoHS
• Single +3.3V power supply
• Real Time Digital Diagnostic Monitoring
• Operating case temperature: 0 to +70°C

Applications

• 40GBASE-SR4 Ethernet
• Switch, router and HBAs
• Infiniband transmission at 4 channels SDR, DDR and QDR
• High-performance Backplane Applications
• Proprietary Protocol Applications

Description

The QSFP+ eSR4 transceivers are high performance, cost effective modules supporting data rate of 40Gbps and 300m transmission distance with MMF.The transceiver consists of three sections: 4 channels 850nm VCSEL array, 4 channels PIN photo detector array and MCU control unit. All modules satisfy class I laser safety requirements.The transceivers are compatible with 40GBASE-SR4 of IEEE802.3ba standard and SFF-8436 specification.

北亿纤通 | F-tone Networks

企业邮箱：sales@f-tone.com
企业网站：www.f-tone.com
企业网站：www.sfpgmk.com
企业电话：028-85255257
企业传真：028-85977702

本产品仅展示部分参数（wn），如有需要，请联系我们。
注：本产品有全国产化型号可选
Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
