40G QSFP+ TO 4X SFP+ Active Copper Cable Assembly

40G QSFP+ TO 4X SFP+ Active Copper Cable Assembly

0.0/5 rating (0 votes)

Description

Features
● QSFP+ End: Compliant with QSFP+ MSA specifications
● SFP+ End: Compliant with SFP+ MSA specifications
● 4 independent duplex channels operating at 10Gbps,also support for 2.5Gbps, 5Gbps data rates
● Single power supply 3.3V, low power consumption
● BER better than 10-12
● EEPROM for cable signature & system communications
● 30 AWG to 26 AWG cable sizes available
● RoHS compliant
● Operating temperature range: 0to 70.

Applications
● 10Gigabit Ethernet
● Serial Data Transmission
● Networking
● Storage
● Fiber Channel

Product Description
F-tone Networks’s FT-77-CAB-Q10/4S-AxM QSFP+ (Quad Small Form-factor PluggablePlus) to 4 SFP+ Active Copper are suitable for very short distances and offer a highly cost-effective way to connect QSFP+ and SFP+ equipment. The direct-attach assemblies support 4 lanes of 10Gbps (40Gbps composite). This interconnect system is fully compliant with QSFP+ MSA and SFP+ MSA
151516






Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
