1.25Gb/s Duplex Fibers SFP Optical Transceiver

Applications
●Applied to optical fiber access Giga Ethernet and Fiber Channel with bit rate up to 1.25Gb/s

Features
● Up to 1.25Gb/s data rate
● Single mode and Multi-mode
● Module integrates receive and transmit circuits of two parts
● All-metal shell and the shell with plastic end plug form, LC receptacle.
● Hot-pluggable
● Metropolitan area network
● Single +3.3V power supply
● Standard PECL data output and input with signal detect indication
● High quality 1310nm MQW-FP LD or 1550nm DFB LD/850nm VCSEL LD
● Commercial level and Industrial level products for customers
● Compliant with SFP MSA
● ROHS compliance

 产品型号:FT-61-M2825-14

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
