0-10Mb/s Duplex Fibers SFP Optical Transceiver

Applications
●Applied to RS232、RS485 optical-electrical converter for electric power control and industrial control with bit rate up to 10Mbps

Features
●Up to 10Mb/s data rate
●Single mode and Multi-mode
●Module integrates receive and transmit circuits of two parts
●All-metal shell and the shell with plastic end plug form, LC receptacle.
●Hot-pluggable
●Metropolitan area network
●Single +3.3V power supply
●Standard PECL data output and input with signal detect indication
●High quality 1310nm MQW-FP LD or 850nm VCSEL LD
●Commercial level and Industrial level products for customers
●Compliant with SFP MSA
● ROHS compliance

 产品型号:FT-61-M2345-14

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
