YGD系列圆形电连接器

产品简介
YGD系列产品符合GJB5371-2005《1G0系列田形电源连接器通用规范》,其连接方式采用卡口连接,接触件端接形式为焊接,捅孔接触件为冠簧捅孔。产品具有快谏连接和分离,耐环境好、可靠性高等特点,适用于大电流电源系列的连接。

产品技术特性
使用环境条件
工作温度:-55℃+125℃
相对湿度:90%-98%
工作气力:4.39kPa~101.33kPa
盐 雾:N类、H类48h、R类、B类96h
密封性:
插座:压差 1.01x10Pa.历时lmin无气泡漏泄
头座插台:1.8m水深48h不渗水
振动:10Hz~2000Hz.196m/s²,瞬断≤1us
冲 击:980m/s² 瞬断≤lus
机械寿命:连接环材料为铝合金时,插拔N500次,连接环材料为铜合金时,插拔2000次

D7D7D7D7D7D7D7D7D7D7D7















 本产品为FT-BH系列圆形电连接器,如有需要,请联系我们。
