产品简介
● 适用于电子、航空、兵器、舰船等系统使用，耐环境能力强，替换FC、LC等民用活动连接器
● 外壳体可选用不同材料及镀层适应不同环境要求
● 三键定位，有盲插和防错插功能
● 快速卡口连接
● 光学对准采用陶瓷插针和套管实现精密对接
● 转接插座，摆脱光缆束缚

主要技术指标
机械性能
● 机械寿命：500次插拔循环
● 冲击：加速2940m/s ² 冲击：加速2940m/s
● 振动：10～2000Hz，加速度0.2g ²/Hz
● 抗拉力：≥68N（适配Φ2光缆的接触件）
环境性能
● 温度范围：-55℃～+85℃
● 盐雾： K类：1000h F类：48h
光学性能
● 插入损耗：≤0.5dB

注：本产品有全国产化型号可选
Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
