J30J微矩型电连接器

产品特点
规格有9、15、21、25、31、37、51、66、74、100芯十种
插头采用 麻花针，产品特点： 高密度、小型化、高可靠
导线 适宜 0.1mm²～0.15mm²
产品性能符合 GJB2446 要求，等效于美军标 MIL--DT-83513
执行标准：
Q/LS-002-2018
《J30J 系列微矩形电连接器详细规范》

技术特性
环境温度：-55℃～+125℃
振 动：10Hz～2000Hz 196m/s²
随机振动 ： 功率谱密度 0.4G7Hz 总加速度均方根值23.1G
冲 击：735m/s² 1lms
额定电流：3A
接触电阻：≤10mQ
绝缘电阻：≥5000MQ
介质耐压：800V
机械寿命 ：500 次

本产品为FT-BH系列圆形电连接器，如有需要，请联系我们。
