北亿纤通专业研发制造6Gbps Video SFP Optical Transceiver,6Gbps Video SFP Optical Transceiver 光纤模块,6Gbps Video SFP Optical Transceiver 光模块,工业级6Gbps Video SFP Optical Transceiver光模块,工业级6Gbps Video SFP Optical Transceiver 光纤模块等等全系列6Gbps Video SFP Optical Transceiver 光纤模块,我司生产的6Gbps Video SFP Optical Transceiver 光纤模块可以完美兼容市面上相应光端机等等光视讯类设备。

Description

The video series transceivers are high performance, cost effective modules for duplex video transmission application over single mode fiber.
The transceiver is designed to transmit/receive data rates from 50Mbps to 11.88Gbps and is specifically designed for robust performance in the presence of SDI pathological patterns for SMPTE 259M, SMPTE 344M, SMPTE 292M, SMPTE 424M, ST2081 and ST-2082 serial rates.
The transceiver consists of three sections: a DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety

Features

● DFB Laser Diode Transmitter

● SD/HD/3G/6G/12G-SDI SFP Transceiver available

● SMPTE ST-297-2006, ST2081 and ST-2082 Compatible

● Metal enclosure for Lower EMI

● 1310nm DFB laser

● Supports video pathological patterns for SD-SDI, HD-SDI,3G-SDI,6G-SDI and 12G SDI

● Compliant with SFP MSA and SFF-8472 with duplex LC receptacle

● Digital Diagnostic functions available through the I2C interface

● Compatible with RoHS

● +3.3V single power supply

● Operating case temperature range (Standard：0 to +70℃) or (Industrial： -40°C to +85°C)

Application

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
