56G QSFP14 Passive Copper Cable Assembly

0.0/5 rating (0 votes)

Description

Features

●Compliant QSFP MSA specification and SFF-8436

●Fully compatible with IEEE802.3ba

●Up to 3m 56Gb/s data rates

●Ultra low crosstalk for improved performance

●Low insertion loss

●100ohm differential impedance system

●AC coupling of PECL signals

●Precision process control for minimization of pair-to-pair skew

●RoHS 6 compliant

Applications

●External storage systems

●Data Center Networking Communications

●Switches and Routers

●InfiniBand Trade Association (IBTA)

Product Description

F-tone Networks’s passive copper cables provide robust connections for leading edge 56Gb/s systems. Passive copper cables require no additional power to ensure quality connectivity. The 56Gb/s passive copper cables are fully compliant with SFF-8436 specification and provide connectivity between devices using QSFP ports. F-tone Networks’s 56Gb/s passive copper cables fillthe need for short, cost-effective connectivity in the data center. Optimizing systems to operate with F-tone Networks’s 56Gb/s passive copper cables significantly reduces power consumption and EMI emission, eliminating the use of EDC hosts.

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
