40G QSFP+ Passive Copper Cable Assembly

40G QSFP+ Passive Copper Cable Assembly

0.0/5 rating (0 votes)

Description



Features
●Compliant QSFP MSA specifications
●Fully compatible with IEEE802.3ba and Infiniband QDR specifications 40 Gb/s total
bandwidth
●4 independent duplex channels operating at 10Gbps,also support for 2.5Gbps, 5Gbps data rates
●100ohm differential impedance system
●Low Near-End Crosstalk(NEXT)
●All-metal housing for superior EMI performance
●Precision process control for minimization of pair-to-pair skew
●AC coupling of PECL signals
●EEPROM for cable signature & system communications
●30 AWG to 24 AWG cable sizes available
●RoHS compliant

Applications
●Data Servers、Routers、Switches
●Networked storage systems
●Data Center networking
●InfiniBand Trade Association (IBTA)
●IEEE-802.3ba
●40Gigabit Ethernet (40GBASE–CR4)

Product Description
QSFP+ (Quad Small Form-factor Pluggable Plus) copper direct-attach cables are suitable for very short distances and offer a highly cost-effective way to establish a 40-Gigabit link between QSFP+ ports of QSFP+ switches within racks and across adjacent racks.
These cables are used for 40GbE and Infniband standards, to maximize performance. QSFP+ are designed to meet emerging data center and high performance computing application needs for a high density cabling interconnect system capable of delivering an aggregate data bandwidth of 40Gb/s. This interconnect system is fully compliant with existing industry standard specifications such as the QSFP MSA and IBTA (InfiniBand Trade Association). The QSFP+ cables support the bandwidth transmission requirements as defined by IEEE 802.3ba (40 Gb/s) and Infiniband QDR (4x10 Gb/s per channel) specifications.
2121







Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
