10Gbps MiniSFF LC Transceiver (10Km)

10Gbps MiniSFF LC Transceiver (10Km)

0.0/5 rating (0 votes)

Description

10Gbps MiniSFF LC Transceiver (10Km)

FEATURES
● Surface mount I/O pins for high speed signal integrity
● All metal body, solder or screw mount options
● Industrial Temp range, vibration tolerant design
● 2-Fiber Mini SFF LC Transceiver
● 1310 DFB transmitter,PIN photo-detector Receiver
● Distance up to 10 km
● Single 3.3V Power Supply
● -40 to 85℃ Operating Temperature

APPLICATIONS
● 10GBASE-LR/LW 10G Ethernet

A10A10













本产品为FT-95-RS系列，仅展示部分参数，如有需要，请联系我们。
Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
