1.25Gbps MiniSFF LC Transceiver (60Km)

1.25Gbps MiniSFF LC Transceiver (60Km)

0.0/5 rating (0 votes)

Description

1.25Gbps MiniSFF LC Transceiver (60Km)

FEATURES
●  Surface mount I/O pins for high speed signal integrity
●  All metal body, solder or screw mount options
●  Industrial Temp range, vibration tolerant design
●  2-Fiber MiniSFF LC Transceiver
●  1550 DFB transmitter,PIN photo-detector Receiver
●  Distance up to 60 km
●  Single 3.3V Power Supply
●  Operating case temperature:
     FT-95-RS-1512-60D : 0℃~+70℃
     FT-95-RS-1512-60DI : -40℃~+85℃

APPLICATIONS
●  SONET/SDH Equipment Interconnect
●  Fiber Channel Links

A17A17

Ordering Information

P/No.

Package

Bit Rate

(Gb/s)

Dist.

(km)

Wavelength

(nm)

TX

Power

(dBm)

RX

Sens

(dBm)

Volt.

(V)

Temp.

(℃)

DDM

FT-95-RS-1512-60D

LC

1.25

60

1550

-3 to +2

-26

3.3

0 ~70

YES

FT-95-RS-1512-60DI

LC

1.25

60

1550

-3 to +2

-26

3.3

-40 ~85

YES













本产品为FT-95-系列,仅展示部分参数,如有需要,请联系我们。
Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
